Product Details
- Many same features of the multiformat, dedicated to 2-3 side seal, standup pouch with or without zipper
- V-board folding with choice of horizontal or vertical folding
- Ultrasonic zipper and apex sealing
- Optional constant motion ball punching
- High speed with fastest setup times in the industry
- Smallest footprint and power usage
Standard Specifications
Machine Width
450mm, 600mm, 850mm, and 1250mm
450mm, 600mm, 850mm, and 1250mm
Speed
50 Meter Per Min. 220 Cycles Per Min.
Machine Dimension
12 Meters x 2 Meters
Material Width
1100mm, 1400mm, 1650mm
1100mm, 1400mm, 1650mm
Control System
PLC & Touch Screen
Unwind Diameter
800mm
800mm
Film Feeding & Scaling
Servo Motor
